[Honkai 3rd]v3.6.1资源加密分析(前)

又是崩坏3ᖗ( ᐛ )ᖘ

中篇: [Honkai 3rd]v3.8.0资源加密分析(中)

在3.5.0版本miHoYo开始加密资源文件，当时正处于考试周加上被ban了一个月所以暂时弃坑，现在重新捡起来。
直接说重点了，首先定位到关键函数CreateDecompressor可以发现传入参数a1即为flag，位于文件0x2E-0x31的四字节整数

switch ( a1 )
  {
    case 0:
      break;
    case 1:
      v2 = operator new(4, a2, 16, nullptr, 55);
      *v2 = &`vtable for'Lz4Decompressor;
      break;
    case 2:
    case 3:
      v2 = operator new(4, a2, 16, nullptr, 52);
      *v2 = &`vtable for'LzmaDecompressor;
      break;
    case 5:
      v2 = operator new(4, a2, 16, nullptr, 59);
      *v2 = &`vtable for'Lz4DecompressorWithDecryption;
      break;

具体代码可以看这里BundleFile.cs#L139
不过这里和AssetStudio有点不一样，mhy给自定义加密设置的flag是0x45，所以解密时会走分支5，区别如下

原版

int Lz4Decompressor::DecompressMemory(Lz4Decompressor *this, void* buffer, int* compressSizePtr, void *decodeBuffer, int* decompressSizePtr)
{
  compressSize = *compressSizePtr;
  decompressSize = *decompressSizePtr;
  result = 0;
  if ( compressSize <= 0x7FFFFFFE && decompressSize <= 0x7FFFFFFE )
  {
    return_decompressSize = UNITY_LZ4_decompress_safe(buffer, decodeBuffer, compressSize, decompressSize);
    result = 0;
    *decompressSizePtr = return_decompressSize;
    if ( return_decompressSize > 0 )
      result = 1;
  }
  return result;
}

自定义版

int Lz4Decompressor::DecompressMemoryWithDecrypt(Lz4Decompressor *this, void* buffer, int* compressSizePtr, void *decodeBuffer, int* decompressSizePtr)
{
  compressSize = *compressSizePtr;
  decompressSize = *decompressSizePtr;
  if ( compressSize > 0xFF )
  {
    buffer = DecryptFunc(buffer, &compressSize);
    result = 0;
    if ( !buffer || compressSize > 0x7FFFFFFE )
      return result;

  }
  else
  {
    result = 0;
  }
  if ( decompressSize <= 0x7FFFFFFE )
  {
    return_decompressSize = UNITY_LZ4_decompress_safe(buffer, decodeBuffer, compressSize, decompressSize);
    result = 0;
    *decompressSizePtr = return_decompressSize;
    if ( return_decompressSize > 0 )
      result = 1;
  }
  return result;
}

可以看到唯一区别就是在自定义版本中数据还要经过DecryptFunc这个函数，当然已经被混淆了，伪代码大概1691行
资源文件分只加密header和还会加密chunk两种情况。后者在数据头部前还有0x14字节以mr0k为开头的数据。最终会调用UNITY_LZ4_decompress_safe解压

只加密header

在恢复文件头部几个关键数据就可以直接用AssetStudio打开
2020-04-03 14:59:25
补图虽然不是同一个文件

还会加密chunk

分3中情况

• 所有chunk全加密 (像excel_output)
• 只加密第一个chunk
• 只加密第二个chunk

反正对着AssetStudio的源代码抄就行，判断一下前4个字节是不是0x6D72306B，是的话走解密，不是就跳过。

[Honkai 3rd]v3.8.0资源加密分析(中)

前篇: [Honkai 3rd]v3.6.1资源加密分析(前)
后篇: [Honkai 3rd]v4.0.0资源加密算法还原(后)

这次miHoYo把所有资源文件打包到wmv文件中，很简单就不多说了，直接对着class BlockFileInfo{}抄一遍。
不过我倒是找到了Header部分的加密算法，位于ArchiveStorageReader::ReadHeader函数下

#include <stdio.h>
#include <stdlib.h>
#include <stdint.h>

int DecryptHeader(unsigned char* EncryptdNum, uint64_t key, unsigned int* keyArray) {
  uint64_t v12 = 4 * key - 0x61C8864E7A143579;
  for (int i = 0; i < 4; ++i) {
    uint64_t tmp = keyArray[0] ^ (keyArray[0] << 11) ^ ((keyArray[0] ^ (keyArray[0] << 11)) >> 8) ^ keyArray[3] ^ (keyArray[3] >> 19);
    keyArray[0] = keyArray[1];
    keyArray[1] = keyArray[2];
    keyArray[2] = keyArray[3];
    keyArray[3] = tmp;
    *(EncryptdNum + i) ^= *(unsigned char*)((uint64_t)&v12 | (tmp & 7));
  }
  return 1;
}

int ReadHeader_CUSTOM(/*void* buffer, int CompressSize*/) {
  /*
  Flags: 45
  BundleSize: 3AC76
  DecompressSize: 97
  CompressSize: 68
  */

  unsigned int Key = 0x16B114C;
  unsigned int Flag = 0xB7989872;
  unsigned int DecompressSize = 0xB1B1B720;
  unsigned int CompressSize = 0xFB10FE3;
  int64_t bundleSize = 0x447937B137E4F841;

  unsigned int KeyArray[4];
  KeyArray[0] = Key;
  KeyArray[1] = 0x6C078965 * KeyArray[0] + 1;
  KeyArray[2] = 0x6C078965 * KeyArray[1] + 1;
  KeyArray[3] = 0x6C078965 * KeyArray[2] + 1;

  if (DecryptHeader((unsigned char*)&Flag, Key, &KeyArray[0]) == 1) {
    printf("Flags: %X\n", Flag);
    if (Key) {
      int64_t DecryptBundleSizeKey = 8 * Key - 0x61C8864E7A143579;
      unsigned int tmp = 0;
      for (int i = 0; i < 8; ++i) {
        tmp = KeyArray[0] ^ (KeyArray[0] << 11);
        KeyArray[0] = KeyArray[1];
        KeyArray[1] = KeyArray[2];
        KeyArray[2] = KeyArray[3];
        KeyArray[3] ^= tmp ^ (tmp >> 8) ^ (KeyArray[3] >> 19);
        *(((unsigned char*)&bundleSize) + i) ^= *(unsigned char*)((int64_t)&DecryptBundleSizeKey | (KeyArray[3] & 7));
      }
      printf("BundleSize: %X\n", (unsigned int)bundleSize);
    }
    DecryptHeader((unsigned char*)&DecompressSize, Key, &KeyArray[0]);
    DecryptHeader((unsigned char*)&CompressSize, Key, &KeyArray[0]);
    printf("DecompressSize: %X\nCompressSize: %X\n", DecompressSize, CompressSize);
  }
  return 1;
}

int main(void) {
  printf("Hello World\n");
  ReadHeader_CUSTOM();
  return 0;
}

随便找一个只加密了header的文件验证一下

扔进去跑出结果

修复文件头


正常打开，完成
buffer部分的解密函数有ollvm混淆，本来准备写ollvm反混淆从入门到跑路来着，但是这次我下载了桌面版，所以事情就变得有趣起来
直接复制目录下UnityPlayer.dll文件路径，调用LoadLibrary加载它，初始化函数后就可以正常调用，觉了
还是拿上一篇文章的例子，可以看到和dump出来的数据一样


就这，最复杂的部分反而是最简单的，不知道为什么鹅厂的虚拟机保护怎么没有把这部分也虚拟化。

[Honkai 3rd]v4.0.0资源加密算法还原(后)

应该是最后一篇了

前篇: [Honkai 3rd]v3.6.1资源加密分析(前)
中篇: [Honkai 3rd]v3.8.0资源加密分析(中)

重新学习清除混淆需要的时间太长，所以最后是直接手撕了。因为是标准的ollvm混淆，所以在调试过程中还算简单，就是很精污。

指令替换

加法混淆

这个被ida pro的反编译器直接优化了，但还是举个例子

rax + rbx = rax - rbp + rbx + rbp
mov     rbp, 0E4F1996E191D8FB0h
sub     rbx, rbp
add     rbx, rax
mov     rax, [rsp+28h]
mov     rsi, [rsp+28h]
shrd    rsi, rax, 33h
add     rbx, rbp

似乎还有另一种情况，在某个每次i+4的循环中

v60 + 1
v60 & 1 | v60 ^ 1

减法混淆也是一样，不举例了。xor混淆

直接就是异或公式(~A & B) | (A & ~B)

v214 = v213 ^ v212
v214 = (~v213 & 0xDB | v213 & 0x24) ^ (~v212 & 0xDB | v212 & 0x24)

and混淆

需要先把xor混淆去掉

v41 = ptr[i] & 0x80000000;
v41 = ptr[i] & (ptr[i] ^ 0x7FFFFFFF);

or混淆

也是要先清除xor混淆

v44 = (B | A) >> 1 ^ ptr[i + 0x9C];
v44 = ((B & A | B ^ A) >> 1) ^ ptr[i + 0x9C];

这几个。不过我觉得还原算法时就算照抄混淆后的伪代码，编译器也会优化回去。
控制流平坦化和伪造控制流没办法了，硬怼( ﾟ∀。)
总之经过快一周的分析之后，得出解密流程如下：

// #####################################################################################
// 计算HashOutput
// #####################################################################################
// 第一步，初始化TheLastOfKeyArray
InitializationTheLastOfKeyArray(&TheLastOfKeyArray);
// 第二步，初始化InitVector
for(int i = 0; i < 0x80; ++i) {
    InitVector[i] = TheLastOfKeyArrayCalc(&TheLastOfKeyArray);
}
// 第三步，初始化HashInput
for(int i = 0; i < 4; ++i) {
    HashInput[i] = TheLastOfKeyArrayCalc(&TheLastOfKeyArray);
}
// 第四步，产生5个hash
HashCalc(&HashOutput, &HashInput);
// #####################################################################################
// 结束
// #####################################################################################
// 第五步，第一次初始化
padding_key(HashOutput, mr0k_key, DecryptionKeyInitVector1, buffer);
// 第六步，循环0x10次
for(int i = 0; i < 0x10; ++i) {
    mr0k_key[i] = DecryptionKeyInitVector1[i] ^ DecryptionKeyInitVector2[i];
}
// 第七步，第二次初始化
padding_key(HashOutput, DecryptionKey, DecryptionKeyInitVector1, buffer);
// 第八步，循环0x10次
for(int i = 0; i < 0x10; ++i) {
    DecryptionKey[i] = DecryptionKeyInitVector1[i] ^ DecryptionKeyInitVector2[i] ^ mr0k_key[i];
}
// 第九步
uint64_t DecryptionKeyInitVector2Int = *DataLenPtr - 0x14 + *(uint64_t*)DecryptionKeyInitVector2;
// 第十步，赋值
DecryptionKeyInt = *(uint64_t*)DecryptionKey;
mr0k_key = *(uint64_t *)mr0k_key;
// 第十一步，最终解密阶段
for(int i = 0; i < 0x80 /*0x400 / 8*/; ++i) {
    DecryptDataPtr[i] ^=
        InitVector[i] ^
        DecryptionKeyInt ^
        DecryptionKeyInitVector2Int ^
        mr0k_key;
}
// 最后返回
*DataLenPtr -= 0x14;
return DecryptBufferStart;

可以看出每次解密只与mr0k_key和DecryptionKey有关，其它部分直接在初始化之后dump出来就行。
所以需要还原的算法只有padding_key这一个，👴像个憨批一样一个个还原人都傻了。

2021-05-18 20:03:42
米桑真不能处，偷偷把算法换了，所以工具已经失效了，也没有更新的打算ᕕ( ᐛ )ᕗ
因为比起还原算法，运行时主动调用解密函数显然更简单，十分钟搞定

以上ᖗ( ᐛ )ᖘ完结撒花~

转载自：https://www.52pojie.cn/thread-1067057-1-1.html

2019-12-02 崩坏3手游3.6版本资源文件加密分析及绕过加密的方法

分析完了，手动解密的确效率低下，撸一串代码，程序解密。

转载自：https://www.52pojie.cn/thread-769195-1-1.html

小白一个，本文并没有什么技术含量。       以前在研究替换unity游戏（崩坏三）的资源文件的时候，发现它所有的shader都被放到了两个加密过的文件里，一个是assetbundle文件item.unity3d,另一个是asset文件sharedassets0.assets。虽然这并不会影响mod的制作，但是还是很想搞明白它是怎么加密解密的。然后就开始了研究。然而并没有找到解密函数，倒是找到了其它文件的解密方法。后来直接分析文件得到了解密方法。           用到的工具：Il2CppDumper，IDA           首先，用IDA分析libil2cpp.so,然后用Il2CppDumper得到大多数函数的名称和字符串。我觉得解密后的数据应该不会保存为文件，应该是从内存中加载，在unity中是用Asssetbundle.loadfrommemory()这个函数加载的。     搜索一下引用，发现两处引用： 转到第一个发现是读取的下载下来的数据： 然后看第二个： 函数名已经很明显了，看一下内容： 看到先用RSA解密出了一个AES密钥，然后用AES解密数据。不过没有密钥，先到Il2CppDumper生成的dump.cs看一下： 再看一下AssetbundleUtility$$.cctor.发现RSA密钥是固定的一个字符串，转到字符串位置得到一个xml格式的RSA密钥： 可以看到 *(_DWORD) (*(_DWORD)(dward_4385ac +80) + 4)是RSA的密钥，那么*(_DWORD) (*(_DWORD)(dward_4385ac + 80) + 8)应该就是用RSA加密过的AES密钥了。IDA连接手机调试得到加密的128字节数据： 之后解密出58字节的数据，根据反编译的代码，数据前32字节是AES的key，之后的16字节是IV，剩下的不知道有什么用。 #更新：剩下的8字节是hmac-sha1的密钥，用于计算文件名中那一串哈希值。 然后发现并不能解密item.unity3d和sharedassets0.assets，两个文件的长度都不是AES算法产生的，最后发现这是用来解密数据文件夹中excel_output_65……868.unity3d和setting_DD……AC9.unity3d这两个文件的，里面是游戏中的各种属性的数据和关卡设计的lua脚本…….. 然后，还是找不到item.unity3d和sharedassets0.assets的解密方法….只好回去分析文件本身。 先对比一下不同版本的item.unity3d:文件开头部分数据是相同的，推测可能是异或加密。 同一unity版本Assetbundle的文件头部大概有30个字节是完全相同的，于是对照未加密的assetbundle手动算出了前32个字节的异或值。然后用sharedassets0.assets来测试，发现可以解密，说明两个文件加密方式和密钥应该是一样的，而且一直没有变过。 解密了前32字节的assets文件：然后，翻到sharedassets0.assets的后面时发现每32字节就会重复出现一段长32字节的类似的数据：然后尝试用算出来的32字节的密钥去循环解密整个文件：结果发现前3M数据中每2kb开头有32字节被解密： 而从0x00300000位置开始之后的数据全都被解密了： 所以前3M数据是2kb的密钥，之后的是32字节的密钥；然后就要想办法解出这2kb的密钥。 在之前已经知道sharedassets0.assets里有很多shader，shader中一部分数据很有规律： 不难发现，在绝大多数”<noninit>”后面至少有5字节的0，所以先用之前的32字节密钥解出对应位置的数据，然后在解出的数据中搜索“<noninit>”，如果之后5个字节中有未解密的数据就直接作为密钥，再解出对应位置的数据，然后继续搜索”<noninit>”,一直循环下去，直到获得完整的密钥。最后得到解密的数据。 解密后的item.unity3d用AssetBundleExtractor打开： 但是，最终也没能找到解密的程序在哪。不知道是我眼瞎没看到还是程序就不在libil2cpp.so里。希望各位大佬指教。 再说一下它这两种加密方式，第一种加密的数据是非常重要的属性数值等数据，用到了RSA来解密AES的密钥，却把RSA的密钥写死在程序里….然后直接IDA调试，到对应的位置直接就可以得到RSA加密过的AES的密钥(之后通过抓包找到了包含加密的密钥的.unity3d文件)…然后第二种异或加密的文件里面主要是shader，不过目前还不能直接看到shader代码（现在也可以看到了..而且也没有加密了），也许是为了防止别的游戏直接拿去用吧，不过用这种算法加密规律的文件。。。 密钥和自己写的加解密程序： 编程不咋地，凑合用吧。  加密解密程序.zip (9.86 KB, 下载次数: 175)

转载自：https://www.twblogs.net/a/5d11f8ecbd9eee1e5c821fba?lang=zh-cn

关于原神文件解密的一篇流水账。。。

米哈游的原神最近开始内测，发现其所有的通过unity加载的资源文件都被加密了。下面就讲一下寻找解密的方法的过程。

游戏是unity 2017.1版本的win64平台，但是却使用了il2cpp,unity2017.1的文档里说明win平台是不支持il2cpp的，不知道怎么做到的，也许是跟unity官方py的？
惯例第一步，先把程序(UserAssembly.dll)丢进IDA里分析。il2cpp第一个加载的文件一定是global-metadata.dat。所以搜索字符串“global-metadata.dat”直接找到加载的函数。

下面是原版的加载函数。

void MetadataCache::Initialize()
{
	s_GlobalMetadata = vm::MetadataLoader::LoadMetadataFile ("global-metadata.dat");
	s_GlobalMetadataHeader = (const Il2CppGlobalMetadataHeader*)s_GlobalMetadata;
	assert (s_GlobalMetadataHeader->sanity == 0xFAB11BAF);
	assert (s_GlobalMetadataHeader->version == 21);

	const Il2CppAssembly* assemblies = (const Il2CppAssembly*)((const char*)s_GlobalMetadata + s_GlobalMetadataHeader->assembliesOffset);
	for (uint32_t i = 0; i < s_GlobalMetadataHeader->assembliesCount / sizeof(Il2CppAssembly); i++)
		il2cpp::vm::Assembly::Register(assemblies + i);
	.....
	.....
}

对照发现没有改动，所以解密部分应该在“vm::MetadataLoader::LoadMetadataFile”函数内部。

//原版的加载函数
void* MetadataLoader::LoadMetadataFile (const char* fileName)
{
	std::string resourcesDirectory = utils::PathUtils::Combine (Runtime::GetDataDir (), "Metadata");
	std::string resourceFilePath = utils::PathUtils::Combine (resourcesDirectory, fileName);
	int error = 0;
	FileHandle* handle = File::Open (resourceFilePath, File::kFileModeOpen, File::kFileAccessRead, File::kFileShareRead, File::kFileOptionsNone, &error);
	if (error != 0)
		return NULL;
	//调用CreateFileMappingW将文件加载到内存
	void* fileBuffer = MemoryMappedFile::Map (handle);
	//在这里添加了解密函数
	File::Close (handle, &error);
	if (error != 0)
	{
		MemoryMappedFile::Unmap (fileBuffer);
		fileBuffer = NULL;
		return NULL;
	}
	return fileBuffer;
}

//添加的解密部分反编译结果
//确认文件开头"mark"标志
if ( !byte_7FFE06F3B110|| _filelen.QuadPart < 4ui64
    || *_filedata != 109 || _filedata[1] != 97
    || _filedata[2] != 114 || _filedata[3] != 107 )
    goto LABEL_46;
   //调用qword_7FFE06F3B100指向的函数，功能为由加密文件长度计算解密后的长度
  v35 = ((__int64 (__fastcall *)(_QWORD))qword_7FFE06F3B100)((LARGE_INTEGER)_filelen.QuadPart);// 获取文件长度
  _filelen_1 = v35;
  _addr = malloc_(v35, 16i64);
  _newaddr = (void *)_addr;
  if ( !_addr )
  {
    UnMapFile(_filedata);
    goto LABEL_47;
  }
  //调用qword_7FFE06F3B108指向的解密函数
  v38 = ((__int64 (__fastcall *)(_QWORD, _QWORD, _QWORD, _QWORD, _QWORD, _QWORD, _QWORD))qword_7FFE06F3B108)(
          _filedata,
          (LARGE_INTEGER)_filelen.QuadPart,
          _addr,
          _filelen_1,
          v39,
          &err,
          -2i64);
......

继续查找引用两个函数指针的函数发现下面一个函数。

void __fastcall il2cpp_enable_confuse(__int64 (__fastcall *a1)(_QWORD), __int64 (__fastcall *a2)(_QWORD, _QWORD, _QWORD, _QWORD, _QWORD, _QWORD, _QWORD))
{
  qword_7FFE06F3B100 = a1;
  qword_7FFE06F3B108 = a2;
  byte_7FFE06F3B110 = 1;
}

函数并没有被dll内部调用，通过动态调试，发现是主程序GS.exe调用的，并且两个解密相关的函数也位于GS.exe内。
接着IDA反编译GS.exe发现解密函数经过了混淆，应该是叫做控制流扁平化。
IDA F5结果

IDA 图形视图

根据米哈游在崩坏三中的做法(详见我在52pojie的文章)，感觉文件依然是异或为主的算法，不同bundle文件的头部也有重合。

然后与未加密的bundle的文件头比较手动算出64字节密钥，发现并不能完全解密文件，于是动态调试从内存中dump出了解密后的global-metadata.dat，发现其长度小于加密的文件(这时候才明白第一个函数是计算大小的)，与加密文件算出的密钥,开头是64字节循环，然后在一段数据后就无法解出正确的数据。然后动态调试下断点发现，在将原数据复制到解密数据的地址时有些数据被忽略了。
所以，为了测试算法(其实直接dump出复制到解密数据存储位置的数据对比一下就能知道哪些数据被去掉了)，准备了两个文件，一个是全为0x00的文件0.dat，另一个是包含递增的int值的文件123.dat，开头四字节设为“mark”，两个文件分别替换global-metadata.dat，并dump出”解密“后的数据0.dnmp和123.dump。其实只是简单的异或的原理了。因为0 xor key = key，所以0.dat经过解密函数后其实就是密钥了。123.dat经过解密函数可以看作加密，密钥就是0.dnmp，123.dump再与0.dump异或即可得到”解密”的文件0123.dat，通过对比123.dat和0123.dat即可知道哪些数据被去掉了。

结果如下图

综上，文件的结构为：
以mark开头，2580(0xA14)字节为一个循环，每个循环按顺序包含四个大块和一个小块，大块为612(0x264)字节数据加4字节无关数据，小块为112(0x70)字节数据加4字节无关数据。最后不足的部分直接结束，不需要补齐。

将开头的mark及无关数据去除后即可循环与64字节的密钥异或解密。经过测试，加密时的无关数据可以随意设置不会有影响。

另外，关于网络修改，https还是抓不到，资源文件流量不走代理，而且服务器会将http重定向到https。不过想改还是有办法的。

转载自：https://katyscode.wordpress.com/2021/01/24/reverse-engineering-adventures-brute-force-function-search-or-how-to-crack-genshin-impact-with-powershell/

————————————————————————————

Today, I thought we’d have a bit of fun and show you a novel and unorthodox alternative way to find any function with known discrete inputs and an assumption about the possible outputs in a compiled application – specifically for this example, a decryption function in a game. We’re going to crack it with PowerShell.

Well, sort of… far be it from me to troll my dear readers with a clickbait title, but there is an element of truth in this. At the very least, to perform this attack your life will definitely be easier if you have some kind of scripting language on hand.

The technique I’m about to describe can be applied to any application which you know contains a specific function with particular arguments and return type, but don’t know where it is located in the binary file.

Problem description

You want to find a function in an executable image. You know the function arguments and return type, but the assembly code is extremely obfuscated and difficult to disassemble, trace or decompile. What can we do?

What if… we just call every address in the image until one of them spits out the expected result?

This can be considered a kind of brute-force attack where the key space is the possible address range of code in the image. It might also be thought of as a kind of reverse fuzzing, where we deliberately pass invalid arguments to every function in an application except for one – where the arguments have been pre-chosen to be valid – to distinguish it from the rest.

Your first thought might be to simply write a piece of code which loads the image and calls every address in a for loop with the desired arguments, then checks the result. Unfortunately, this won’t work. Most of the time you will be calling into the middle of a function, or in the case of architectures such as x86 which uses variable instruction length, you may also be calling into the middle of an instruction that may end up being an invalid opcode.

Many of the calls you make to valid instructions will lead to stack corruption, as the end of the function will pop values off the stack that were never pushed on at the start, since those instructions were skipped. The majority of the rest of the calls will result in the function using invalid or uninitialized register or memory data, which will lead to undefined behaviour and quite probably crash the calling process.

The way we can deal with this is by using two processes: one which calls a specified address in the image – the “client process”, and a second process which contains a for loop that repeatedly invokes the first process for each address – the “host process”. If the client process crashes, the host process simply moves to the next iteration of the loop and re-invokes it.

About today’s case study

(you can skip this section if you don’t care about Genshin Impact; the details are not relevant to the main exercise in the article)

miHoYo’s open world action RPG Genshin Impact – or Gacha Impact as I like to call it – has seen a surge of popularity since it was launched in September 2020. It uses more or less the same protection from automatic reverse engineering by IL2CPP tools like Il2CppInspector as Honkai Impact, but with a substantially higher level of security:

• process memory can no longer be dumped by tools like ProcDump (in Genshin Impact 1.1)
• assembly instruction-level obfuscation is used to prevent the code from being decompiled in both the main exe and UnityPlayer.dll
• UnityPlayer.dll now has anti-debugging countermeasures

They’re learning! There are also a couple of minor kinks:

• some additional initialization is required prior to the metadata decryption step. Without this, one extra XOR step will be required after decrypting global-metadata.dat to fully recover the plaintext. The initialization code is heavily obfuscated but easily mitigated by determining the required XOR transformation from the partially decrypted file (see end of article for more details)
• the fake decoy API il2cpp_thread_get_name in the main game DLL which receives pointers to the decryption functions from UnityPlayer.dll was renamed to il2cpp_init_security (another decoy API name) and the “authentication check” was removed

I have produced an extensive four-part series on how to reverse engineer Honkai Impact for IL2CPP tooling, so refer to those articles for more details – virtually all of it is equally applicable to Genshin Impact and you can use exactly the same techniques to reverse engineer this game.

I’ll be working with Genshin Impact 1.1 today but the technique should be equally applicable to any version. Full disclosure, I did not reverse engineer it in the traditional way first, so there was no cheating involved!

The function

In this example, we shall look for a function which has the following signature:

uint8_t *Decrypt(uint8_t *encryptedData, uint32_t length);

The function receives a blob of encrypted data and the length of the data as its input arguments, and returns a pointer to a decrypted blob of the same length. We have the encrypted data stored in a file (which in this case is called global-metadata.dat) and therefore also know its length. We also make assumptions about the content of the decrypted data. We have to know something – anything – about the output so that we can validate any results we get to check if we have found the correct function.

In this case, the input file contains repeating blocks of 0x40 bytes that are encrypted, surrounded by unencrypted areas. For example:

In this portion of the file, part of a table is encrypted. We can reasonably assume that the data at offsets like 0x240908 is 95 5F 00 00 05 00 00 00, or at the very least that the last byte of this sequence is zero if nothing else.

It doesn’t matter if you don’t have access to this insight: if the entire file is encrypted, but you know the decrypted result contains some string, some sequence of bytes, starts or ends with a particular byte etc., you can just search the output to see if it matches your criteria after each function call. This is called a known plaintext attack.

For this particular example, we don’t know for sure the function exists, but we are assuming it does based on the fact that previous, less obfuscated versions of the game have a function with the same behaviour, derived from static analysis of those versions. The encryption algorithm may be different in the image being analyzed, but that doesn’t matter as long as the function signature is the same: the goal is to decrypt the data, not to discern the algorithm itself.

Watch out, it’s the fuzz!

We begin the proceedings by creating a small C# project which will load the image, call the function at the virtual address specified as a command-line argument and check the result.

Immediately we hit a stumbling block: certain kinds of unmanaged exceptions such as stack overflows and access violations (attempts to access memory outside the bounds of the process, or to write or execute read-only memory) are converted to corrupted state exceptions (CSEs) in .NET. By default, these are not handled and the application will crash.

.NET Framework 3.5 and onwards provide a mechanism to handle this scenario by adding the HandleProcessCorruptedStateExceptions and SecurityCritical attributes to a method which may generate CSEs. They can then be captured as a regular managed exception in a try...catch block. As of .NET Framework 4.0, the SecurityCritical attribute is no longer required.

using System;
using System.IO;
using System.Runtime.ExceptionServices;
using System.Runtime.InteropServices;
// ...

[DllImport("kernel32.dll", SetLastError = true, CharSet = CharSet.Auto)]
private extern static IntPtr LoadLibrary(string path);

[DllImport("kernel32.dll")]
private extern static bool FreeLibrary(IntPtr hModule);
// ...

[UnmanagedFunctionPointer(CallingConvention.Cdecl)]
private delegate IntPtr DecryptDelegate(byte[] encryptedData, int length);
// ...

[HandleProcessCorruptedStateExceptions]
public static void Main(string[] args) {
    var hModule = LoadLibrary("UnityPlayer.dll");
    var encryptedData = File.ReadAllBytes("global-metadata.dat");
    var length = encryptedData.Length;

    var offset = (int) (Convert.ToInt64(args[0], 16) - 0x180000000);
    var rva = hModule + offset;

    var Decrypt = (DecryptDelegate) Marshal.GetDelegateForFunctionPointer(rva, typeof(DecryptDelegate));

    Console.WriteLine($"Trying {offset:x8}");

    try {
        var decrypted = Decrypt(encryptedData, length);

        byte[] decryptedData = new byte[length];
        Marshal.Copy(decrypted, decryptedData, 0, length);

        Console.WriteLine("Saving...");
        File.WriteAllBytes($"possibly-decrypted-{offset:x8}.dat", decryptedData);
    }
    catch (Exception ex) {
        Console.WriteLine("Exception thrown - " + ex.GetType().Name + " - " + ex.Message);
    }
    finally {
        FreeLibrary(hModule);
    }
}

CSE handling is not implemented in .NET Core (any version) or .NET 5, and the attribute type is defined but has no effect. Therefore we cannot use .NET Core for this task, so I have compiled the code below against .NET Framework 4.8.

We don’t strictly need to handle CSEs and can just let the process crash, but we may want to produce logging output to help in our analysis later. By handling them, we have the opportunity to write to a log file before terminating the process.

Here then is our first stab at the code:

Lines 7-11 import LoadLibrary and FreeLibrary from the Win32 API to enable us to load an unmanaged DLL at runtime.

Lines 14-15 define the calling convention and signature of the function we wish to find.

Line 20 loads the target image (UnityPlayer.dll in this case) and lines 21-22 prepare the function arguments. In this case we load the encrypted data file and retrieve its length.

We will supply the virtual address of the function to call as the command-line argument. Line 24 interprets the hex string supplied on the command-line as an integer, and subtracts the image’s preferred base address (which you can find from the image file’s PE header), leaving us with the file offset of the address to call. Line 25 then adds this offset to the actual image base address after it is loaded in memory to determine the memory location to call into.

Line 27 creates a managed delegate that allows us to call the desired function at the memory address we just calculated, with the correct argument and return types.

Line 32 attempts to actually invoke the function in the image, and more often than not will throw an exception.

Lines 34-35 retrieve the result of the function call (a byte array in this case) and line 38 saves it to a file so that we can inspect it, suffixing the filename with the address offset used so that if we are successful we’ll actually know the correct function address.

Line 41 handles any thrown exceptions including CSEs and line 44 unloads the DLL from memory, in a finally block so that it executes whether or not an exception was thrown.

Once we’ve compiled the project, we can invoke it on the command line as follows:

./FunctionSearch.exe 1800123456

Output:

Trying 00123456

Nothing else happens in this case, indicating some other kind of unhandled unmanaged exception that just causes the process to terminate. This is fine and will be the case much of the time.

Host in the shell

We can now construct a very simple PowerShell script to call this process in a loop with every possible address, as follows:

for ($a = 0x180000000; $a -le 0x1FFFFFFFF; $a++)
{
	$aHex = $a.ToString('x')
	Start-Process -FilePath ./FunctionSearch.exe -ArgumentList "$aHex" -NoNewWindow
}

The first line of the loop converts the loop value into a hexadecimal string. The second line creates a new process for our C# code, passing in the address argument. The -NoNewWindow switch redirects output to the existing PowerShell console rather than opening a new window for each new process.

This script does not wait for the process to end before starting another one, so it will essentially queue them up as fast as your hardware allows. The output looks like this:

Trying 00000000
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Trying 00000001
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Trying 00000002
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Trying 00000003
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Trying 00000004
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.

The client process crashes most of the time, but the host script continues to start new processes with new address arguments without any problems.

The Need For Speed

The image file I’m attacking here is 32.3MB – 0x205B870 possible addresses. Execution time per call will vary, but on my 24-core machine – and with the files stored on an SSD – this script iterates through about 0x200 (512) functions per minute and adds 7% to the CPU consumption. That means it will take 46 days to test every address – just a whisker shy of how long it takes to count votes in Pennsylvania. Statistics dictate that on average you’ll have to test half of the addresses in any given image to find the correct one, so we’re looking at 23 days on average per similar DLL we have to iterate through. It’s fair to say we are travelling at less than 50mph.

We can improve the search efficiency by pruning the search space. We know that the majority of addresses are mid-function or mid-instruction, and a good portion will not even be in the code section(s) of the image. If IDA or your disassembler of choice is able to find the start of every function (assuming the assembly-level obfuscation is not to a level that completely destroys its ability to sweep through the code – if it is you’re out of luck and will have to skip to the next section), we can dramatically reduce the number of addresses we have to test.

The plan is to build a text file containing a list of potential addresses to scan, and modify our script to read lines from this file instead of using a numeric for loop.

Here is how to do this with IDA, but you can achieve similar results with other disassemblers:

1. Load the image into IDA

2. Wait for a really long time. Hopefully not longer than 46 days, but you never know with IDA. IDA will populate the Functions window (Shift+F3) with most of the functions it finds within a few minutes, but for an absolutely complete list, you may need to wait several hours

3. Right-click in the Functions window and choose Copy all, or just press Ctrl+Shift+Ins (because IDA loves keyboard shortcuts that make sense)

4. Create a new document in a text editor that supports regular expression replacement and paste in the function list (Visual Studio Code: Ctrl+N, Ctrl+V). You will now have text that looks like this:

Function name	Segment	Start	Length	Locals	Arguments	R	F	L	S	B	T	=
sub_180001000	.text	0000000180001000	00000003	00000000	00000000	R	.	.	.	.	.	.
sub_180001020	.text	0000000180001020	00000004	00000000	00000000	R	.	.	.	.	.	.
sub_180001030	.text	0000000180001030	000000BB	00000018	00000038	R	.	.	.	B	.	.
sub_1800010EB	.text	00000001800010EB	000000A9	00000018	00000040	R	.	.	.	B	.	.
sub_1800012CC	.text	00000001800012CC	00000138	00000018	0000002C	R	.	.	.	B	.	.
sub_180001404	.text	0000000180001404	000000D9	00000018	0000002C	R	.	.	.	B	.	.

5. Delete the first line

6. Replace all using the regex search term ^(.?)\t(.?)\t([0-9A-Fa-f]{16}).*$ and the replacement term $3. This regex isolates the address as the 3rd match group and discards everything else on the line (Visual Studio Code: Ctrl+H, Alt+R, enter regex, Tab, enter replacement, Ctrl+Alt+Enter). The file will now look like this:

0000000180001000
0000000180001020
0000000180001030
00000001800010EB
00000001800012CC
0000000180001404

7. Save it as function-list.txt in the same folder as the script

We will now modify the script we created above to read in each line of the file sequentially and pass it as an argument to the client process:

$functionListFile = "function-list.txt"

foreach ($line in Get-Content $functionListFile)
{
	Start-Process -FilePath ./FunctionSearch.exe -ArgumentList "$line" -NoNewWindow
}

The output now looks like this:

Trying 00001030
Trying 00001020
Trying 000010eb
Trying 00001000
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Trying 0000167e
Trying 000012cc
Trying 00001404
Trying 000014e0
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.
Exception thrown - AccessViolationException - Attempted to read or write protected memory. This is often an indication that other memory is corrupt.

(note that output and error messages are displayed out of order since multiple client processes can be running simultaneously and at different stages of execution, and all are sharing the same console)

For this example, this narrows the search space from almost 34 million addresses to a scant 77,033 – a handy reduction by a factor of 50. Execution time goes up, however, as more actually valid code is executed. This time my machine chewed through 350 per minute for an estimated total runtime of 220 minutes, or about 3.6 hours – not great, not terrible.

Stop! In The Name of Mov

There is a problem with our script as it stands now: sometimes the client process will hang as the function call results in an infinite loop or fails to acquire a spinlock or mutex. This will eventually fill up the available memory with hung processes, and possibly bring down the entire machine. We can mitigate this by allowing the process a certain amount of time to execute, then killing it if the timeout expires. The following updated script accomplishes this:

$functionListFile = "function-list.txt"

foreach ($line in Get-Content $functionListFile)
{
	$proc = Start-Process -FilePath ./FunctionSearch.exe -ArgumentList "$line" -PassThru -NoNewWindow

	$timeout = $null
	$proc | Wait-Process -Timeout 10 -ErrorAction SilentlyContinue -ErrorVariable timeout

	if ($timeout) {
		echo "Timeout - killing process"
		$proc | kill
	}
}

There are a few points of interest here. Normally, Start-Process does not return anything. By adding the -PassThru switch, a Process object will be returned, which we store in $proc and can use to query and control the process after it starts (line 5).

Line 8 pipes the stored Process object to Wait-Process, which waits for a process to exit. By specifying the -Timeout option, we instruct the cmdlet to wait for a maximum number of seconds, after which the script will continue executing regardless of whether the client process has exited or not.

If a timeout has occurred, the variable whose name we pass to Wait-Process in the -ErrorVariable action will be non-null. We check for this on line 10, and kill the process on line 12 in the event of a timeout. This is not a very clean or elegant way of ending a process, but it works for our purposes.

This solution guarantees that the script won’t get stuck or exhaust the available hardware resources, but it also has the side effect of only allowing one client process to run at a time, since we wait to see whether it times out or not before starting the next one. This is actually good for accurate logging to understand what’s happening on each call, but bad for search efficiency. Now we’re only hitting 44 calls per minute, for a total maximum runtime of 29 hours. Ouch.

50mph is not going to be enough. We need to get all the way to 88mph.

Where we’re going, we don’t need code

Even on a low-end PC, we won’t be coming close to saturating the available compute resources with our current solution. Unless the storage media is a bottleneck, we can improve performance by splitting the work up into threads to increase CPU utilization. Tasks like this where each test can run independently are an excellent candidate for parallelization, as there are no synchronization considerations to worry about.

In this demo, we’re actually going to spin up a large number of PowerShell instances, so we will be splitting the work across processes rather than threads. Creating a process is – relatively speaking – computationally expensive, but we will only perform this spin-up at the beginning of the search so it’s not a big deal in this case. The plan is to run multiple instances of the script we’ve already created in parallel, in separate processes, and give each instance a different set of addresses to scan.

First, we need to split the function address list up into chunks, one chunk for each host process. If you skipped the previous section because your target code is obfuscated in a way that prevents you from deriving the function addresses, you can instead split up the entire address range into chunks instead.

Tip: If you don’t have a list of function address candidates and need to scan every address, just use the range in the .text section and any other code/executable sections. The .data and related sections are unlikely to contain code. In the event you don’t find anything after scanning the code address ranges, you can try to search the data address ranges as a last resort.

We can sit in our text editor and copy paste all day, or we can write another PowerShell script to do it for us. This is especially useful if we decide to change the chunk size (to have more or less processes running at once) or if we need to regenerate the address range from scratch and split it up again.

Here is the script:

The details are rather boring, but it essentially takes two arguments: the text file and the line number multiple to split on, calculates the number of files needed, then writes them all with “_PartX” appended.

Usage:

This will split the list into chunks of 1500 addresses:

We replace the hard-coded $functionListFile in our previous script with a command-line argument so that we can specify a different address range file for each instance:

Finally, we need a startup script to launch an instance of the search script for each of the search ranges (text files):

(in this example, splitting the list up into 1500-item chunks generated 52 files – change as appropriate for your application)

This script starts one instance for each address range file without waiting for any of them to finish, so they all run simultaneously. This is going to spew a massive amount of PowerShell windows onto your screen. Don’t be afraid!

You should also see close to 100% CPU utilization. If you don’t, split the function list into smaller chunks and start more instances. If your PC falls over into a crumpled heap, split the function list into larger chunks and start less instances! One instance per CPU hardware thread is a good starting baseline.

The work will not be distributed 100% evenly because some functions will take longer to execute than others, and there will also be timeouts. Rather elegantly, each PowerShell window will close once its search range completes, so you can just keep an eye on this to track the progress.

You will likely see various error dialogs as the scan runs:

Don’t worry about these. There is no need to close them: our script will kill the process after 10 seconds anyway.

Watching the scan can be highly informative about other functions in the application. Here is a sample of messages that came up during the run for our example DLL:

On my machine, all of the PowerShell instances ended within a few minutes of each other, and the total runtime at which the last instance completed was 93 minutes – about a 19x improvement over the single-host process version, which is about what you’d expect from a 24-core CPU.

Note: This can be improved quite a bit further. You can create a pool of client processes per host process without waiting for them to finish, then each time a process in the pool completes or times out, you create a new client process with the next address to test. This will allow the host script to cycle through other client processes while one of them is hung.

You make the startup script count the number of files matching a filter like function-list-Part*.txt so that the loop counter upper bound is not hard-coded.

You can alter the text file split script to specify how many chunks you want instead of what line to split on.

You can also dispense with splitting the file altogether and simply alter the host script to take the starting line number and a count as input, and change the startup script to use a numeric for loop with the count per host script as the stepping factor. This is actually a subjectively better solution, but I didn’t have time to rework the script in time for this article unfortunately.

In League with The /dev/null

We’ve set up our scanner nicely, but so far we haven’t actually done anything with the results. If the function you’re looking for returns an int or some other simple type, we’ve just discarded it. If you are outputting another file, you probably ran out of disk space:

The demo scan above generated 2,292 files @ 32.3MB each for a cool 73GB consumed disk space. Yikes.

Let’s add some checks and filters to the client process so that it can test if the return value contains or at least resembles the expected results. The code to implement this is completely dependent on the target function at hand, but I will demonstrate my approach for this encrypted file with some general rules of thumb.

If you are dealing with a pointer to a returned block of memory as in this case, there are some things to bear in mind:

• some functions will initialize a block of memory with all zeroes. Of the files generated by our scan, quite a lot of them were just all-zero, or had large all-zero areas
• some functions will copy the input, ignore the input arguments (because the real function being called doesn’t take any arguments) or otherwise have no noticeable effect, and the output will be the same as the input, or garbage
• some functions will initialize a fixed amount of memory, meaning the start of the return data will be zeroes or meaningful data, and the rest will be garbage

The upshot of all this is that if we’re working with a large data set – as we are here with a 32MB byte array – you will want to try and avoid writing filters that examine the beginning of the data where possible. This is the area that is most likely to trigger the most false positives when you try to write code that analyzes it for validity automatically.

That being said, you also need to be very careful not to be too aggressive with your filtering, otherwise you may accidentally filter out the correct function – and indeed this happened to me as I was producing this example, since an area I assumed would be zeroes in the decrypted data actually wasn’t. It is generally better to have to look through 100 results by hand than narrowing it down to 10, realizing none of them are correct and having to run the entire scan again with looser filter criteria.

For illustration, I’ll describe how I filtered the results for this exercise. I started by identifying a region of the file that should definitely change once it had been decrypted, by simply scrolling through it with a hex editor:

As mentioned earlier, the file has periodic blocks of 0x40 encrypted bytes. The region 0xC0300-0xC033F above seems to be encrypted, and should change if we can force it to be decrypted. We select this region as the first test area and store the original bytes for this region in an array:

Right before the code which saves the file, we insert a test:

This simply compares the original data with the data copied from the result pointer and exits the process if they are the same (the return statement will cause the finally block to execute to free the DLL, then return control to the Powershell host script).

As we just discussed, it’s possible we got back a big ol’ empty block of zeroes, so we also filter out these results:

If the maximum byte value of the region is zero, then all the bytes are zero (you can also use .All(x => x == 0) if you prefer).

This deals with the no change and all-zero scenarios, but it’s all possible we get junk back. Here we do the opposite: take a region near the start of the file which should not be changed (in this case the first 0x40 bytes are encrypted and the next 0x40 bytes are unencrypted), and test it to make sure that it has not changed:

When we make these changes and re-run the scan using just the functions that generated file output last time, the overall output resembles this snippet:

Tip: If you want to tighten the filter then re-run the scan using only the subset of candidate addresses which already produced file outputs in the last run, you can generate a new address range list based on the generated files like this:

ls possibly-decrypted-*.dat | % { echo ([int] ("0x" + $_.Name.Substring(19,8)) +
0x180000000).ToString('X16') } > function-list-new.txt

This enumerates all of the generated files, extracts only the offset portion of each filename, converts the hex strings to integers, adds the image preferred base address to each, converts them back into strings and outputs the new set of addresses as a list to the specified file.

How many output files do we get now?

One.

Let’s take a look inside at the same region as before:

Smokin’! We decrypted the data – or at least most of it. The 16 bytes at 0xC0300 are still messed up, but that is a complication unique to Genshin Impact; the main point is we have proven that the correct function has been found – and that is how you brute-force a function address with PowerShell. Nicely done!

We came, we predicted, we scripted and decrypted

(you can skip this section if you don’t care about Genshin Impact; the details are not relevant to the main exercise in the article)

In the case of our particular case study, there are still 16 bytes of not fully-decrypted data per block. By looking through the data by eye, we can easily see that this can be resolved by a 16-byte XOR operation per block. All that is required is to derive the XOR term by manual inspection. Here are a few blocks (in Genshin Impact 1.1 they occur every 0x26700 bytes on the PC version and every 0x24B80 bytes on the Android version):

I chose these more or less at random. The XOR term can be derived based on the surrounding context. If there is an obvious pattern in the previous or following group of bytes, you can XOR an encrypted byte with the corresponding unencrypted byte to derive part of the term as follows:

• Block 1: ?? 2F 42 30 ?? (23^27) (B2^02) 9C ?? 2A C0 BA ?? (98^27) (A7^02) 68
• Block 2: no further information
• Block 3: no further information
• Block 4: (AE^03) .. .. .. ((3^5) << 4 + ?) .. .. .. (9E^03) .. .. .. ((5^5) << 4 + ?) .. .. ..

XOR term so far:

To find the remaining two nibbles we can save a bit of time by searching the file for parts of the term we have already found to try to find an obvious solution. We try AD 2F 42:

The non-zero numbers only occur every 4th byte so we can safely conclude the missing bytes are 67 and 0E for a final term of:

And that’s it! By calling the decryption function, then XORing the first 16 bytes of each encrypted block with this value, we can now fully decrypt the metadata file.

Might as well JMP

The amount of code we reverse engineered in this exercise was zero. We merely used prior knowledge from a previous, less obfuscated product and a visual survey of the input data. This completely defeats all of the extra security measures employed with relative ease.

Setting up the initial test harness is a bit cumbersome, but once in place it can now be re-used for any function in any application with near-zero effort. All you need to do is change the function delegate, input arguments and output filter in the C# client code and generate a new list of addresses to scan.

Since the function we found in this particular DLL is a hidden export, the developers are going to have a hard time preventing this kind of attack. While significantly hardening the application against both static and dynamic analysis via assembly-level obfuscation and anti-debug traps, they completely neglected to consider that none of it matters if you can trivially find the entry point. It’s like building a huge layer cake with tunnel vision, and not realizing someone can just stick their finger straight into the lowest layer and lick off the chocolate.

While the developers could change the function signature, this would be a temporary workaround at best. Perhaps least bad solution here is probably to move the decryption functions into the game binary so they are not imports, and inline them in another function so there is no obvious entry point. This technique can be further improved by adding an argument to the enclosing function as a behaviour (code path) selector – perhaps merging a large collection of other functions together – so that the intent becomes very unclear. Of course, this will significantly impact the readability and maintainability of the original source code, especially if the merged functions require different argument types.

Another option could be to split the logic of the single target function into multiple functions to increase the search complexity. One will have to be aware of and find multiple functions, and call them in the correct order. The actual search time would only increase linearly with the number of additional functions; however, deriving the correct arguments for each could increase the complexity exponentially if implemented correctly. If the attacker does not know the function arguments, then the overall search space is a factor of the image size, the number of functions to find and the possible range of inputs to each.

As obfuscation developers find ever-more intricate mechanisms to deploy, so too must analysts learn to think outside the box and pursue attack vectors the obfuscation authors may not have thought of. The attack I outlined today is certainly not new and I take absolutely no credit for it, however I haven’t seen much coverage of it on the internet with practical working examples so I hope you found it insightful! Obfuscation techniques will continue to evolve inexorably, as will the tooling available to reverse engineer them. This cat and mouse game has been in progress since long before the rise of the modern internet. The cats are always on the prowl – and whenever they try something new, this mouse will be here, waiting for them.
